Geist Monitored Unit Level EC MN05M2R1-16IB48-3TL6A0H10-S

MSRP$1,564.00
$1,117.00
Geist Monitored Unit Level EC MN05M2R1-16IB48-3TL6A0H10-S
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Power distribution unit (rack-mountable)
  • AC 208 V
  • 4.9 kW
  • Ethernet 10/100/1000, RS-232, USB
  • input: NEMA L6-30P
Geist Monitored Unit Level EC MN05M2R1-16IB48-3TL6A0H10-S
  • Power distribution unit (rack-mountable)
  • AC 208 V
  • 4.9 kW
  • Ethernet 10/100/1000, RS-232, USB
  • input: NEMA L6-30P
  • output connectors: 16 (power IEC 60320 C13, IEC 60320 C19)
  • 2U
  • 19"
  • 3 m cord
  • black powder coat
  • TAA Compliant
  Additional Details
Price: $1,117.00
MSRP: $1,564.00
Mfr Part #: VP4N32A0
SHI Part #: 48664954
Category: Rack systems for rack mount electroni...
UNSPSC: 24102001
Manufacturer: Vertiv
Product Type: Hardware
General Information
CategoryRack systems for rack mount electroni...
DescriptionGeist Monitored Unit Level EC MN05M2R1-16IB48-3TL6A0H10-S - Power distribution unit (rack-mountable) - AC 208 V - 4.9 kW - Ethernet 10/100/1000, RS-232, USB - input: NEMA L6-30P - output connectors: 16 (power IEC 60320 C13, IEC 60320 C19) - 2U - 19" - 3 m cord - black powder coat - TAA Compliant
ManufacturerVertiv
MSRP$1,564.00
UNSPSC24102001
Main Specifications
Dimensions & Weight / Depth22.9 cm
Dimensions & Weight / Height8.64 cm
Dimensions & Weight / Width43.2 cm
General / SubcategoryPower distribution devices
Header / BrandGeist
Miscellaneous / Product ColorBlack
Networking / Remote Management Interface
  • Ethernet 10/100/1000
  • RS-232
  • USB
Packaged Quantity1
Power Device / Form FactorRack-mountable
Power Device / Output Connector Qty16
Power Device / Voltage RequiredAC 208 V
Product TypePower distribution unit
Service & Support / Type5-year warranty with product registration
Dimensions & Weight
Depth22.9 cm
Height8.64 cm
Width43.2 cm
Dimensions & Weight (Shipping)
Shipping Weight6.35 kg
Environmental Parameters
Max Operating Temperature60 °C
Expansion / Connectivity
Interfaces
  • 1 x management (RS-232) - RJ-45
  • 1 x USB
  • 2 x management (Ethernet) - RJ-45
  • Sensor - RJ-12
General
ColorBlack powder coat
Cord Length3 m
Device TypePower distribution unit - rack-mountable
Height (Rack Units)2U
Rack Size19"
Manufacturer Warranty
Service & Support
  • Limited warranty - 5 years with product registration (within 120 days of purchase)
  • Limited warranty - 3 years
Miscellaneous
Cables IncludedPower cable 3 m
Compliant StandardsANSI C12.1, FCC, FCC Part 15 A, IEC 62053-21, RoHS, UL/CUL 62368-1
FeaturesRJ45 port, horizontal mount, power monitoring, USB interface, integrated RS232, circuit/breaker current monitoring, daisy chain functionality, double pole magnetic breaker, touch screen LCD display, internal RMS current sensor, internal RMS voltage sensor, upgradeable, twist lock plug, hard reboot button, IP reset button
Rack Mounting KitIncluded
TAA CompliantYes
Networking
Remote Management InterfaceEthernet 10/100/1000, RS-232, USB
Remote Management ProtocolDHCP, HTTP, HTTPS, IPv4, IPv6, LDAP, NTP, RADIUS, RSTP, SSH, SMTP, Syslog, TACACS+, SNMP 1, SNMP 2c, SNMP 3
Power Device
Frequency Provided50/60 Hz
Input Connectors1 x power NEMA L6-30P
Input VoltageAC 208 V
Max Electric Current30 A
Output Voltage200 - 240 V 50/60 Hz
Power Capacity4.9 kW
Power Output Connectors Details
  • 12 x power IEC 60320 C13
  • 4 x power IEC 60320 C19
