HPE ProLiant Compute DL360 Gen12
MSRP$12,801.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
HPE ProLiant Compute DL360 Gen12
- Server
- rack-mountable 1U
- 1 x Xeon 6507P / up to 4.3 GHz
- RAM 64 GB
- hot-swap 2.5" bay(s)
- SSD 2 x 480 GB
- no OS
- monitor: none
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $12,801.00 |
| Mfr Part #: | P89998-005 |
| SHI Part #: | 51133058 |
| Category: | Servers |
| UNSPSC: | 43211501 |
| Manufacturer: | Hewlett Packard Enterprise |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Servers |
| Description | HPE ProLiant Compute DL360 Gen12 - Server - rack-mountable 1U - 1 x Xeon 6507P / up to 4.3 GHz - RAM 64 GB - hot-swap 2.5" bay(s) - SSD 2 x 480 GB - no OS - monitor: none |
| Manufacturer | Hewlett Packard Enterprise |
| MSRP | $12,801.00 |
| UNSPSC | 43211501 |
| Main Specifications | |
| Chassis / Form Factor | Rack-mountable |
| Chassis / Server Storage Bays | Hot-swap |
| Dimensions & Weight / Depth | 77.31 cm |
| Dimensions & Weight / Height | 4.29 cm |
| Dimensions & Weight / Weight | 14.87 kg |
| Dimensions & Weight / Width | 43.46 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 480 GB |
| Header / Brand | HPE |
| Header / Country Kits | North America |
| Miscellaneous / Product Color |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | No operating system |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 3.5 GHz |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | 8-core |
| Processor / Processor Number | 6507P |
| Processor / Type | Xeon |
| RAM / Form Factor | DIMM 288-pin |
| RAM / Technology | DDR5 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 960 GB |
| System / Type | Server |
| Cache Memory | |
| Cache Per Processor | 48 MB |
| Installed Size | L3 cache - 48 MB |
| Dimensions & Weight | |
| Depth | 77.31 cm |
| Height | 4.29 cm |
| Weight | 14.87 kg |
| Width | 43.46 cm |
| Environmental Parameters | |
| Humidity Range Operating | 8 - 90% RH (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 10 °C |
| Expansion / Connectivity | |
| Bays | 8 (total) / 6 (free) x hot-swap 2.5" SFF |
| Interfaces |
|
| Slots |
|
| General | |
| Built-in Devices | LED panel |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Hot-Swap Bays Qty | 8 |
| Localization | Region: North America |
| Product Form Factor | Rack-mountable - 1U |
| Type | Server |
| Graphics Controller | |
| Video Interfaces | VGA |
| Video Memory | 16 MB |
| Hard Drive | |
| Capacity | 2 x 480 GB |
| Type | SSD |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site |
| Miscellaneous | |
| Compliant Standards | AES, IPv6 Ready, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, Redfish API, UEFI, ErP Lot 9, PCIe 5.0, DMTF, Active Directory v1.0, UEFI Class 3, ACPI 6.5, SMBIOS 3.7, UEFI 2.10 |
| Monitor | |
| Monitor Type | None. |
| Operating System / Software | |
| OS Provided | No operating system |
| Software | HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE OneView Advanced |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| 80 PLUS Certification | 80 PLUS Titanium |
| Device Type | Power supply - hot-plug |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Provided | 1000 watt |
| Power Redundancy | Yes |
| Power Redundancy Scheme | 1+1 |
| Voltage Required | AC 100-240 V |
| Processor / Chipset | |
| Clock Speed | 3.5 GHz |
| CPU | Intel Xeon 6507P |
| CPU Qty | 1 |
| CPU Upgradability | Upgradable |
| Max CPU Qty | 2 |
| Max Turbo Speed | 4.3 GHz |
| Number of Cores | 8-core |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, 16 Threads, 150W TDP |
| RAM | |
| Configuration Features | 2 x 32 GB |
| Effective Memory Speed | 6400 MT/s |
| Features | Registered, HPE SmartMemory, slots 17 - 32 are available in two-processor configuration only |
| Form Factor | DIMM 288-pin |
| Installed Size | 64 GB (installed) / 256 GB (max) |
| Rated Memory Speed | 6400 MT/s |
| Slots | 32 (total) / 30 (empty) |
| Technology | DDR5 SDRAM |
| Storage Controller | |
| Buffer Size | 4 GB |
| Channel Qty | 8 |
| Storage Controller Name | HPE MR408i-o Gen11 SPDM |
| Type | 1 x RAID - OCP 3.0 |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 4.0 |
| EPEAT Compliant | EPEAT Silver |
