Hardware Computers and Tablets Desktops and Workstations
Add to My Favorites
Desktops and Workstations

HP Workstation Z2 G9

Login for Price
HP Workstation Z2 G9
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • AI Workstation
  • tower 4U
  • 1 x Core i7 12700 / up to 4.9 GHz
  • RAM 32 GB
  • SSD 512 GB
HP Workstation Z2 G9
  • AI Workstation
  • tower 4U
  • 1 x Core i7 12700 / up to 4.9 GHz
  • RAM 32 GB
  • SSD 512 GB
  • HP Z Turbo Drive, NVMe, TLC
  • T400
  • Gigabit Ethernet
  • Win 10 Pro (includes Win 11 Pro License)
  • monitor: none
  • keyboard: US
  Additional Details
Mfr Part #: 6K344UA#ABA
SHI Part #: 46767934
Category: Desktop computers
UNSPSC: 43211507
Manufacturer: HP, Inc.
Product Type: Hardware
General Information
CategoryDesktop computers
DescriptionHP Workstation Z2 G9 - AI Workstation - tower 4U - 1 x Core i7 12700 / up to 4.9 GHz - RAM 32 GB - SSD 512 GB - HP Z Turbo Drive, NVMe, TLC - T400 - Gigabit Ethernet - Win 10 Pro (includes Win 11 Pro License) - monitor: none - keyboard: US
ManufacturerHP, Inc.
UNSPSC43211507
Main Specifications
Chassis / Form FactorTower
Dimensions & Weight / Depth38.5 cm
Dimensions & Weight / Height35.6 cm
Dimensions & Weight / Weight7.2 kg
Dimensions & Weight / Width16.9 cm
Display / TypeNone.
Hard Drive / Capacity512 GB
Hard Drive / InterfacePCI Express 4.0 x4
Hard Drive / Interface TypePCI Express 4.0 x4
Header / BrandHP
Header / Country KitsUnited States
Header / LocalizationEnglish
Mainboard / Chipset TypeIntel W680
Mainboard / Processor SocketLGA1700 Socket
Miscellaneous / Product ColorBlack
Networking / Data Link Protocol
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Optical Storage / Drive TypeNo optical drive
Optical Storage / TypeNone
OS Provided / TypeWindows 10 Pro
Packaged Quantity1
Processor / Clock Speed2.1 GHz
Processor / Generation12
Processor / ManufacturerIntel
Processor / Number of Cores12-core
Processor / Processor NumberI7-12700
Processor / TypeCore i7
RAM / Data Integrity CheckNon-ECC
RAM / Form FactorDIMM 288-pin
RAM / Memory Speed4800 MHz
RAM / TechnologyDDR5 SDRAM
Service & Support / Type3-year warranty
System / Hard Drive Capacity512 GB
System / TypeWorkstation
Video Output / Graphics ProcessorNVIDIA T400 / Intel UHD Graphics 770
Audio Output
Compliant StandardsHigh Definition Audio
Cache Memory
Cache Per Processor25 MB
Installed SizeL3 cache - 25 MB
Dimensions & Weight
Depth38.5 cm
Height35.6 cm
Weight7.2 kg
Width16.9 cm
Dimensions & Weight (Shipping)
Shipping Depth49 cm
Shipping Height51.8 cm
Shipping Width29.5 cm
Environmental Parameters
Humidity Range Operating10 - 85% RH (non-condensing)
Max Operating Temperature35 °C
Min Operating Temperature5 °C
Expansion / Connectivity
Bays
  • 1 (total) / 1 (free) x external 5.25"
  • 1 (total) / 1 (free) x external 5.25" Slim Line
  • 2 (total) / 2 (free) x internal 3.5"
  • 1 (total) / 1 (free) x internal 2.5"
Interfaces
  • 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support)
  • 6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging)
  • 1 x audio line-in
  • 1 x audio line-out
  • 2 x DisplayPort 1.4
  • 3 x USB 2.0
  • 1 x USB 3.2 Gen 1
  • 1 x LAN (Gigabit Ethernet)
Slots
  • 1 (total) / 0 (free) x PCIe 5.0 x16
  • 1 (total) / 1 (free) x PCIe 3.0 x4
  • 1 (total) / 1 (free) x PCIe 3.0 x16
  • 1 (total) / 1 (free) x PCIe 3.0 x4
  • 3 (total) / 2 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode)
  • 1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module)
General
AI LevelAI Workstation
Embedded SecurityTrusted Platform Module (TPM 2.0) Security Chip
LocalizationLanguage: English / region: United States
Product Form FactorTower - 4U
TypeWorkstation
Graphics Controller
Graphics ProcessorNVIDIA T400 / Intel UHD Graphics 770
Multi-GPU Configuration1 single GPU card / integrated GPU
Video InterfacesDisplayPort
Hard Drive
Capacity1 x 512 GB
FeaturesHP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Interface TypePCI Express 4.0 x4
TypeSSD - M.2 2280
Input Device
TypeMouse, keyboard
Keyboard
InterfaceUSB
Keyboard NameHP 320K
Localization & LayoutUS
Manufacturer Warranty
Service & SupportLimited warranty - parts and labor - 3 years - on-site
Miscellaneous
Compliant StandardsRoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen
Security Slot TypeKensington security slot
Theft/Intrusion ProtectionSecurity lock slot (cable lock sold separately)
Monitor
Monitor TypeNone.
Mouse
Mouse NameHP 320M
Networking
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
Operating System / Software
OS ProvidedWindows 10 Pro (available through downgrade rights from Windows 11 Pro) + Windows 11 Pro License - English
SoftwareHP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager, HP ZCentral Remote Boost, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0
Optical Storage
TypeNo optical drive
Power
Device TypePower supply
Efficiency90%
Power Factor CorrectionYes (active)
Power Provided450 watt
Voltage RequiredAC 90-269 V (50/60 Hz)
Processor / Chipset
Chipset TypeIntel W680
Clock Speed2.1 GHz
CPUIntel Core i7 (12th Gen) 12700
CPU Qty1
CPU SocketLGA1700 Socket
CPU UpgradabilityUpgradable
Max CPU Qty1
Max Turbo Speed4.9 GHz
Number of Cores12-core
Processor Main FeaturesIntel Turbo Boost Technology
RAM
Configuration Features2 x 16 GB
Effective Memory Speed4800 MHz
FeaturesUnbuffered
Form FactorDIMM 288-pin
Installed Size32 GB (installed) / 128 GB (max)
Rated Memory Speed4800 MHz
Slots4 (total) / 2 (empty)
TechnologyDDR5 SDRAM - non-ECC
Storage Controller
Channel Qty4
Controller Interface TypeSATA 6Gb/s / PCIe 4.0 x4 (NVMe)
RAID LevelRAID 0, RAID 1
Type1 x SATA/NVMe
Sustainability Information
ENERGY STAR CertifiedYes
EPEAT CompliantEPEAT Gold
