StarTech.com Wall Plate HDMI over CAT5 Extender with Power Over Cable HDMI CAT5 or CAT6 Audio Video Extender Kit 1080p 165ft (50m) (ST121HDWP)

Mfr Part #:

Copied To Clipboard

Click To Copy

SHI Part #:

Copied To Clipboard

Click To Copy

Quick Details
Video/audio extender up to 50 m for P/N: FPWHANGER, SVA12M2NEUA, SVA12M5NA

StarTech.com Wall Plate HDMI over CAT5 Extender with Power Over Cable HDMI CAT5 or CAT6 Audio Video Extender Kit 1080p 165ft (50m) (ST121HDWP)

Video/audio extender
up to 50 m
for P/N: FPWHANGER, SVA12M2NEUA, SVA12M5NA

Additional Details
Mfr Part #:	ST121HDWP
SHI Part #:	29817602
Category:	Serial port cards
UNSPSC:	43201559
Manufacturer:	StarTech.com
Product Type:	Hardware

Extend HDMI up to 165ft (50m) over Cat5e/6 cabling with a wall plate finish, and power the extender from a single power source on either side of the connection. The ST121HDWP HDMI over CAT5 Extender Wall Plate Kit lets you extend your HDMI audio/video up to 165 feet (50 meters) over Cat5e or Cat6 cabling. For a seamless, professional installation, you can install the included transmitter and receiver units into wall plates, with the added versatility of Power Over Cable enabling both units to be powered by the same single power source.

Unlike some video extension systems, the ST121HDWP lets you make use of your existing Cat5 or Cat6 networking cable infrastructure, saving you the time and cost of running expensive proprietary cable. Plus, the kit includes both the extender and receiver, saving you the hassle of buying each component individually.

With a sleek finish and wall plate housing, the ST121HDWP is designed with professional installations in mind. Offering a stylish integration into your modern boardroom or classroom, the HDMI extender looks great in any application that requires your equipment and cabling to be concealed from public view.

The HDMI extender is great for both short and long-range applications. With a discreet installation the extender is perfect for boardrooms, restaurants, hotels, classrooms and lecture halls. Plus, because the ST121HDWP can extend your signal up to 165 feet (50 meters) over Cat5, you can achieve a total distance of 197ft using HDMI cables up to 5m (16ft) long at both the transmitter and receiver ends - perfect for long range digital signage applications.

For installation flexibility, the extender offers the unique benefit of an optional external power adapter, giving you the option to power your extender externally for ease of installation, or internally with a 12V DC terminal to discreetly hide your power source.

Audio/Video Cables

Startech 6ft (2m) HDMI Cable, 4K High Speed HDMI Cable with Ethernet, UHD 4K 30Hz Video, HDMI 1.4 Cable, Ultra HD HDMI Monitors, Projectors, TVs & Displays, Black HDMI Cord

6ft HDMI Cable (Male/Male)
HDMI cable
HDMI male to HDMI male
1.8 m
double shielded
black

MSRP $14.34

$13.99

StarTech.com 15 ft High Speed HDMI Cable

Ultra HD 4k x 2k HDMI Cable
HDMI to HDMI M/M
15ft HDMI 1.4 Cable
Audio/Video Gold-Plated (HDMM15)
HDMI cable
HDMI (M) to HDMI (M)

$20.00

StarTech.com 10 ft High Speed HDMI Cable

Ultra HD 4k x 2k HDMI Cable
HDMI to HDMI M/M
10ft HDMI 1.4 Cable
Audio/Video Gold-Plated (HDMM10)
HDMI cable
HDMI (M) to HDMI (M)

MSRP $20.49

$19.99

Network Cables

StarTech.com 1000ft CAT5e Ethernet Cable

Blue
Bulk Roll
Solid UTP Cable
CMR Rated
Box of CAT5e Network Wire Cable (WIRC5ECMR)
Bulk cable

$204.00

StarTech.com 1000 ft Bulk Roll of Gray CMR Cat5e Solid UTP Cable

RJ45 Patch Cable
Cat 5e Patch Cable
Cat5e Patch Cable (WIRC5ECMRGRY)
Bulk cable
304.8 m
UTP

$204.00

Startech Cat 5e RJ45 Solid Modular Plug Connector

Network connector
RJ-45 (M)
CAT 5e
clear (pack of 50)
for P/N: ST121HDWP, STUTPWALLA, WIRC5ECMR

MSRP $45.09

$41.00

General Information
Category	Serial port cards
Description	StarTech.com Wall Plate HDMI over CAT5 Extender with Power Over Cable HDMI CAT5 or CAT6 Audio Video Extender Kit 1080p 165ft (50m) (ST121HDWP) - Video/audio extender - up to 50 m - for P/N: FPWHANGER, SVA12M2NEUA, SVA12M5NA
Manufacturer	StarTech.com
UNSPSC	43201559
Main Specifications
Dimensions & Weight / Depth	4.3 cm
Dimensions & Weight / Height	10.5 cm
Dimensions & Weight / Weight	428 g
Dimensions & Weight / Width	4.5 cm
Header / Brand	Startech StarTech.com
Header / Country Kits	Europe North America United Kingdom
Networking / Connectivity Technology	Wired
Networking / Form Factor	External
Networking / Type	Video/audio extender
Packaged Quantity	1
Service & Support / Type	2-year warranty
Compatibility Information
Designed For	P/N: FPWHANGER, FPWTLTPORT, MBLTVSTNDEC, SVA12M2NEUA, SVA12M5NA
Dimensions & Weight
Depth	4.3 cm
Height	10.5 cm
Weight	428 g
Width	4.5 cm
Environmental Parameters
Humidity Range Operating	0 - 80%
Max Operating Temperature	40 °C
Min Operating Temperature	0 °C
Expansion / Connectivity
Interfaces	1 x HDMI (input) - 19 pin HDMI Type A female 1 x Ethernet (input) - RJ-45 female 1 x HDMI (output) - 19 pin HDMI Type A female 1 x Ethernet (output) - RJ-45 female
General
Device Type	Video/audio extender
Form Factor	External
Localization	North America, United Kingdom, Europe
Manufacturer Warranty
Service & Support	Limited warranty - 2 years
Miscellaneous
Compliant Standards	FCC, RoHS
Networking
Connectivity Technology	Wired
Features	Wall mountable, 7.1 channel audio support
Max Resolution	1920 x 1200 / 1080p
Max Transfer Distance	50 m
Power
Power Device	External power adapter
Power Over Ethernet (PoE)	PoE
Voltage Required	AC 120/230 V
