Hanwha Vision WiseNet X XNV-8083RX
MSRP$1,555.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Hanwha Vision WiseNet X XNV-8083RX
- Network surveillance camera
- PTZ
- dome
- outdoor
- vandal-proof
- color (Day&Night)
- 6 MP
- 3328 x 1872
- auto iris
- motorized
- audio
- composite
- GbE
- MJPEG, H.264, H.265
- DC 12 V / PoE Plus
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $1,555.00 |
| Mfr Part #: | XNV-8083RX |
| SHI Part #: | 46053598 |
| Category: | Digital cameras |
| UNSPSC: | 45121504 |
| Manufacturer: | HANWHA VISION |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Digital cameras |
| Description | Hanwha Vision WiseNet X XNV-8083RX - Network surveillance camera - PTZ - dome - outdoor - vandal-proof - color (Day&Night) - 6 MP - 3328 x 1872 - auto iris - motorized - audio - composite - GbE - MJPEG, H.264, H.265 - DC 12 V / PoE Plus |
| Manufacturer | HANWHA VISION |
| MSRP | $1,555.00 |
| UNSPSC | 45121504 |
| Main Specifications | |
| Dimensions & Weight / Depth | 13.77 cm |
| Dimensions & Weight / Height | 10.49 cm |
| Dimensions & Weight / Weight | 750 g |
| Dimensions & Weight / Width | 13.77 cm |
| Header / Brand | Hanwha Techwin |
| Miscellaneous / Product Color | Black |
| Packaged Quantity | 1 |
| Camera | |
| Digital Video Capture Resolution | 3328 x 1872, 3072 x 1728, 2592 x 1944, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240, 2688 x 1520 |
| Digital Video Format | MJPEG, H.264, H.265 |
| Exposure Range | 2 sec - 1/12000 sec |
| Features | Backlight Compensation (BLC), Highlight Compensation (HLC), Wide Dynamic Range (WDR), Samsung Super Dynamic Range (SSDR), Extreme WDR, image flip, image mirror, Hallway View, Object Detection, Virtual Line detection, loitering detection, intrusion detection, entrance / exit detection, Defocus Detection, motion detection, tamper-detection, fog detection, Audio Detection, shock detection, appearing / disappearing detection, Vehicle Detection, Person Detection, ONVIF (Profile S) support, ONVIF (Profile G) support, ONVIF (Profile T) support, ONVIF (Profile M) support, WiseStream II support, WiseStream III support, Defog, Gain Control, anti-flicker, Lens Distortion Compensation (LDC), face detection, license plate detection, white balance, Constant Bitrate (CBR), Variable Bitrate (VBR), Trusted Platform Module (TPM), sound classification, IP address filtering, digest authentication, user access log, Unicast Streaming, Multicast Streaming, Handover, notification picture to FTP, notification picture to E-mail, Heat Map, people counting, queue management, built-in gyroscope, Privacy Mask Function, WiseNR II |
| Flash Memory | 512 MB |
| Frame Rate (max) | 30 frames per second |
| Infrared Distance | 50 m |
| Infrared LEDs | Yes |
| Max Digital Video Resolution | 3328 x 1872 |
| Minimum Illumination |
|
| Motion Detection | Yes |
| RAM | 4 GB |
| Type | Color - Day&Night - pan / tilt / zoom - outdoor - vandal-proof |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | -50 °C |
| Relative Humidity (operating) | 0 - 95% RH (non-condensing) |
| Expansion / Connectivity | |
| Ports |
|
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| General | |
| Audio Formats | G.711, U-LAW, G.726, ADPCM, AAC-LC |
| Audio Support | Yes: two-way audio capability |
| Connectivity Technology | Wired |
| Depth | 13.77 cm |
| Device Type | Network surveillance camera |
| Form Factor | Dome |
| Height | 10.49 cm |
| Weight | 750 g |
| Width | 13.77 cm |
| Image Sensor | |
| Type | 6 MP CMOS 1/1.8" |
| Interfaces | |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP, RTCP, RTSP, NTP, HTTP, HTTPS, SSL, TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMP 1, SNMP 2c, SNMP 3, ARP, DNS, DDNS, QOS, UPnP, Bonjour, LLDP, SRTP, EAP |
| Video | Composite video |
| Lens Construction | |
| Diagonal Field of View (degree) | 54 - 138 |
| Focal Length | 4.4 mm - 9.3 mm |
| Focus Adjustment | Automatic, manual |
| Horizontal Field of View (degree) | 47 - 113 |
| Lens Iris | F/1.3-2.15 auto iris (DC, P-Iris) |
| Min Focus Distance | 50 cm |
| Optical Zoom | 2.1 x |
| Type | Motorized zoom |
| Vertical Field of View (degree) | 26 - 58 |
| Miscellaneous | |
| Color | Black |
| Compliant Standards | IP66, IP67, IP6K9K, NEMA Type 4X, IK10+, IEEE 802.3at, IPv4, IPv6 |
| Panning | |
| Range (degree) | 0 to 360 |
| Power | |
| Power Device | Power adapter / PoE 22.5 watt |
| Power Requirements | DC 12 V / PoE Plus |
| Tilting | |
| Range (degree) | -45 to +85 |
