GALAXY VS UPS 50KW 480V FOR EXTERNAL BATTERIES, START-UP 5X8
MSRP$43,775.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
GALAXY VS UPS 50KW 480V FOR EXTERNAL BATTERIES, START-UP 5X8
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $43,775.00 |
| Mfr Part #: | GVSUPS50KGS |
| SHI Part #: | 47793957 |
| Category: | Uninterruptible power supplies |
| UNSPSC: | 39121011 |
| Manufacturer: | APC by Schneider Electric |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Uninterruptible power supplies |
| Description | GALAXY VS UPS 50KW 480V FOR EXTERNAL BATTERIES, START-UP 5X8 |
| Manufacturer | APC by Schneider Electric |
| MSRP | $43,775.00 |
| UNSPSC | 39121011 |
| Main Specifications | |
| ABC Code | B |
| Height | 0.00 |
| Length | 0.00 |
| One Source Flag | YNN N |
| Serialized Flag | Y |
| SKU Created Date | 250131 |
| Width | 0.00 |
| Battery | |
| Type | No battery |
| Dimensions & Weight | |
| Depth | 84.7 cm |
| Height | 148.5 cm |
| Weight | 210 kg |
| Width | 52.1 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 99 cm |
| Shipping Height | 168 cm |
| Shipping Weight | 235 kg |
| Shipping Width | 64 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 61 dB |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x SmartSlot |
| General | |
| Bundled Services | Start-Up Service 5X8 |
| Color | RAL 9003 |
| Device Type | UPS - external |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year - on-site |
| Miscellaneous | |
| Compliant Standards | IEC 62040-3, FCC Part 15 A, IP21, CSA C22.2 No. 107.3, IEC 60721-4-2, UL 1778 5th edition |
| Features | Touch screen interface, audible alarm, Parallel Capability, built-in static bypass, touch screen LCD display |
| Included Accessories | Dust filter |
| Power Device | |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 40 - 70 Hz |
| Input Connectors | 1 x hardwire 4-wire (3PH + G) |
| Input Voltage | AC 480 V |
| Input Voltage Margin | ± 3% |
| Input Voltage Range | AC 408 - 552 V |
| Input Wiring | 3-phase |
| Output Voltage | 480 V ± 3% - 50/60 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 50 kW / 50000 VA |
| Power Output Connectors Details |
|
| UPS Technology | On-line |
| Sustainability Information | |
| ENERGY STAR | Yes |
