Newline STV-5524-PLUS
MSRP$1,199.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Newline STV-5524-PLUS
- 55" Diagonal Class STV+ Series LED-backlit LCD display
- interactive digital signage
- Android
- 4K UHD (2160p) 3840 x 2160
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $1,199.00 |
| Mfr Part #: | STV-5524-PLUS |
| SHI Part #: | 49029305 |
| Category: | Flat panel displays |
| UNSPSC: | 43211902 |
| Manufacturer: | Newline Interactive |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Flat panel displays |
| Description | Newline STV-5524-PLUS - 55" Diagonal Class STV+ Series LED-backlit LCD display - interactive digital signage - Android - 4K UHD (2160p) 3840 x 2160 |
| Manufacturer | Newline Interactive |
| MSRP | $1,199.00 |
| UNSPSC | 43211902 |
| Main Specifications | |
| Dimensions & Weight / Depth | 8.76 cm |
| Dimensions & Weight / Height | 70.9 cm |
| Dimensions & Weight / Weight | 11.3 kg |
| Dimensions & Weight / Width | 123 cm |
| Display / Diagonal Size | 55 in |
| Header / Brand | Newline |
| Miscellaneous / Product Color | Black |
| Television / Brightness | 260 cd/m² |
| Television / Diagonal Size | 55 in |
| Television / Diagonal Size (cm) | 140 cm |
| Television / Display Format | 4K UHD (2160p) |
| Television / Image Aspect Ratio | 16:9 |
| Television / Resolution | 3840 x 2160 |
| Television / Type | LED-backlit LCD flat panel display |
| Television / Viewing Angle | 178° |
| Audio System | |
| Output Power / Total | 20 watt |
| Speaker System | 2 speakers |
| Speakers | 2 x main channel speaker - 10 watt |
| Connections | |
| Connector Type |
|
| Dimensions & Weight (Shipping) | |
| Depth (Shipping) | 14.4 cm |
| Height (Shipping) | 83.7 cm |
| Weight (Shipping) | 15.6 kg |
| Width (Shipping) | 135 cm |
| Display | |
| Additional Features | 1.07 billion colors (8-bit+FRC) |
| Brightness | 260 cd/m² |
| Coating | Anti-glare, 2% haze |
| Color Support | 1070000000 colors |
| Commercial Features | Newline Display Management |
| Display Format | 4K UHD (2160p) |
| Dynamic Contrast Ratio | 4000:1 |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Image Aspect Ratio | 16:9 |
| LCD Backlight Technology | LED backlight |
| Operation Hours / Days | 24 / 7 |
| Pixel Pitch | 0.105 mm |
| Resolution | 3840 x 2160 |
| Response Time | 6.5 ms |
| Viewing Angle | 178° |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 80% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| General | |
| Commercial Use | Yes - interactive digital signage |
| Depth | 8.76 cm |
| Design | Ultra thin bezel |
| Diagonal Class | 55" |
| HDMI Ports Qty | 3 ports |
| Height | 70.9 cm |
| Modes | Landscape mode, Fast Boot mode |
| Operating System | Android OS 14 |
| Platform | Android |
| Power Consumption (Max) | 140 watt |
| Power Consumption Operational | 140 watt |
| Product Type | LED-backlit LCD flat panel display |
| Series | STV+ Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI, component |
| Weight | 11.3 kg |
| Width | 123 cm |
| Media Player | |
| Configuration | ARM Cortex-A73 Quad-Core - 4 GB - 16 GB - ARM Mali-G52 MC1 |
| USB Port | Yes |
| USB Ports Qty | 2 |
| Network & Internet Multimedia | |
| Bluetooth Version | Bluetooth 5.0 |
| Connect & Share | IP Control |
| Connectivity | Bluetooth, LAN, Wi-Fi |
| LAN Protocol | Ethernet |
| Wi-Fi Protocol | 802.11ac |
| Power | |
| Features | Wake on WLAN, WOL (Wake on LAN) |
| Input Voltage | AC 110-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 watt |
| Power Device | Power supply |
| Remote Control | |
| Battery Form Factor | AAA type |
| Battery Included | Yes |
| Battery Included Qty | 2 |
| Battery Required Qty | 2 |
| Type | Remote control |
| Stands & Mounts | |
| Flat Panel Mount Interface | 400 x 300 mm |
| VESA Compatibility | Yes |
