HPE Aruba Networking CX 8100 24p SFP+ 25G 4p QSFP28 100G

MSRP$22,200.00
$18,942.00
HPE Aruba Networking CX 8100 24p SFP+ 25G 4p QSFP28 100G
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Switch
  • horizontal surface mounting only
  • L3
  • managed
  • 24 x 1 Gigabit / 10 Gigabit SFP / SFP+ + 4 x 40 Gigabit QSFP+ / 100 Gigabit QSFP28
HPE Aruba Networking CX 8100 24p SFP+ 25G 4p QSFP28 100G
  • Switch
  • horizontal surface mounting only
  • L3
  • managed
  • 24 x 1 Gigabit / 10 Gigabit SFP / SFP+ + 4 x 40 Gigabit QSFP+ / 100 Gigabit QSFP28
  • back to front airflow
  • rack-mountable
  Additional Details
Price: $18,942.00
MSRP: $22,200.00
Mfr Part #: S6B76A
SHI Part #: 50713528
Category: Network switches
UNSPSC: 43222612
Manufacturer: Hewlett Packard Enterprise
Product Type: Hardware
General Information
CategoryNetwork switches
DescriptionHPE Aruba Networking CX 8100 24p SFP+ 25G 4p QSFP28 100G - Switch - horizontal surface mounting only - L3 - managed - 24 x 1 Gigabit / 10 Gigabit SFP / SFP+ + 4 x 40 Gigabit QSFP+ / 100 Gigabit QSFP28 - back to front airflow - rack-mountable
ManufacturerHewlett Packard Enterprise
MSRP$22,200.00
UNSPSC43222612
Main Specifications
Header / BrandAruba
Miscellaneous / Product ColorBlack
Networking / Form FactorRack-mountable
Networking / Ports Qty24
Networking / TypeSwitch
Packaged Quantity1
Service & Support / TypeLimited lifetime warranty
System Requirements / OS RequiredAOS-CX
Environmental Parameters
Humidity Range Operating15 - 95% RH @ 40°C (non-condensing)
Humidity Range Storage15 - 95% @ 65 °C (non-condensing)
Max Operating Temperature40 °C
Max Storage Temperature70 °C
Min Operating Temperature0 °C
Min Storage Temperature-40 °C
Expansion / Connectivity
Interfaces
  • 24 x Gigabit / 10Gbit LAN SFP+
  • 4 x 40/100Gbit LAN QSFP28/QSFP+ uplink
  • 1 x USB-C console
  • 1 x serial RJ-45
  • 1 x USB Type A
General
Authentication MethodSecure Shell (SSH), TACACS+, RADIUS, Secure Shell v.2 (SSH2)
Capacity
  • Packet buffer size: 32 MB
  • IPv4 host table capacity: 65536
  • IPv6 host table capacity: 65536
  • IPv4 routes (Unicast): 24576
  • IPv6 routes (Unicast): 12288
  • IPv4 ACL entries (ingress): 16384
  • IPv6 ACL entries (ingress): 4096
  • MAC ACL entries (ingress): 16384
  • IPv4 ACL entries (egress): 2048
  • IPv6 ACL entries (egress): 512
  • MAC ACL entries (egress): 2048
  • Maximum number of VLANs: 1024
  • IGMP groups: 4096
  • MLD groups: 4096
  • IPv4 routes (Multicast): 4096
  • IPv6 routes (Multicast): 4096
Compliant StandardsIEEE 802.1ab (LLDP), IEEE 802.1ak, IEEE 802.1AX, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1t, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3an, IEEE 802.3by, IEEE 802.3ba, IEEE 802.3cc, IEEE 802.3bj, IEEE 802.3z, IEEE 802.3x
Device TypeSwitch - 24 ports - L3 - managed
Enclosure TypeBack to front airflow rack-mountable 1U
FeaturesDCB, QoS, SP, DWRR, layer 2 switching, BPDU, RoCE, RoCE v2, Aruba VSX, VRRP support, BFD, ERPS, UDLD, sFlow, NTP, port mirroring, RPVST+, Dynamic VXLAN with BGP-EVPN, Address Resolution Protocol, layer 3 routing, OSPF, BGP-4, policy based routing, ECMP, GRE
Flash Memory32 GB
MAC Address Table Size147456 entries
Performance
  • Switching capacity: 1.28 Tbps
  • Throughput: 952 Mpps
Ports24 x 1 Gigabit / 10 Gigabit SFP / SFP+ + 4 x 40 Gigabit QSFP+ / 100 Gigabit QSFP28
Processor1 x ARM Cortex-A72: 1.8 GHz
RAM16 GB
Remote Management ProtocolSNMP, SNMP 2, SNMP 3, MIB
Routing ProtocolMLD, MLDv2, IGMP, IGMPv2, IGMPv3, BGP-4, RIP-2
Subtype10 Gigabit Ethernet
Manufacturer Warranty
Service & SupportLimited warranty - lifetime
Miscellaneous
Compliant StandardsEN 63000:2018, EN 62368-1:2014 Second Edition, UL 62368-1, CSA C22.2 No. 62368-1, IEC 62368-1: 2014, IEC 62368-1:2018, EN55032:2015, CISPR 32 Class A, FCC CFR 47 Part 15: 2018 Class A, ICES-003 Class A, CNS 13438 Class A, KN32 Class A, VCCI Class A, AS/NZS CISPR 32 Class A, EN 55035:2017, CISPR 35, IEC/EN 61000-4-2, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-11, EN IEC 61000-3-2:2019, EN 61000-3-3:2013, IEC 61000-3-3:2013, EN 60825-1:2014, IEC 60825-1:2014 Class 1, Laser Class 1
Included Accessories3 x field-replacable hot-swappable fan trays
Power
Installed Qty2
Max Supported Qty2
Power DeviceInternal power supply - hot-plug
Voltage RequiredAC 100-127/200-240 V (50/60 Hz)
Software / System Requirements
OS RequiredAOS-CX
